WEBINAR

Optimizing semiconductor processing through wettability measurements on wafers

April 9th, 2025

Session 1 - 10:00 AM - 11:00 AM CEST | Session 2 - 4:00 PM - 05:00 PM CEST

Wettability measurements are gaining interest in semiconductor applications due to their ability to provide valuable information on surface properties in a fast and non-invasive fashion. Instruments dedicated to wettability measurements on wafers are thus sought after with an emphasis on the software tailored to serve the needs of this high-tech industrial sector.

In this webinar, you will learn more about:

  • How contact angle measurements are utilized in semiconductor research.

  • The key capabilities provided by tensiometers to support your work.

Presenter

susanna

Susanna Laurén
Marketing Director Attension & KSV NIMA
Biolin Scientific

Register
